ASTM TP 304 Inox Stainless Steel Pipe Tube 309S 310S 316ti 321 347H 2507

Product Categories
Wuxi Laiyuan Special Steel Co., Ltd.
Contact Now

ASTM TP 304 Inox Stainless Steel Pipe Tube 309S 310S 316ti 321 347H 2507

Brand Name : TISCO, BAOSTEEL

Model Number : Stainless Steel Coil

Certification : SGS, BV

Place of Origin : China

MOQ : 1 ton

Price : To be negotiated

Payment Terms : L/C, T/T

Supply Ability : 8,000 ton per ton

Delivery Time : 10-15 days after advance payment

Packaging Details : Kraft paper, wooden case,packaging according to customer requirements

Name : ASTM TP 304 Inox Stainless Steel Pipe Tube 309S 310S 316ti 321 347H 2507

Grade : 316Ti

Width : 600--1800mm al available

Thickness : 0.3-120mm,0.1mm-100mm,0.15-3.0mm,0.3-3mm,0.2-0.8mm

Type : Pipe

Color : Natural Color,blue for normal use,RAL Colors,all APL color available,Bright white

Price term : CIF,FOB,CIF CFR FOB EX-WORK,EXW

Material : 201 202 304 316Ti 321 410 420 904L 2205

Contact Now

ASTM TP 304 Inox Stainless Steel Pipe Tube 309S 310S 316ti 321 347H 2507



GENERAL PROPERTIES

Austenitic stainless steels are amongst the most widely used classes of metals. Primarily, many austenitic alloys such as Stainless Steel 316Ti Seamless Pipe are preferred over carbon steels for several reasons. The principal reason for their use is corrosion resistance. For a piping system to survive in environments, corrosion resistance is an integral property. With corrosion resistance higher than grade 304, the ASTM A312 TP 316TI pipe delivers excellent performance



Specification





Specifications ASTM A213 and ASME SA213
Dimensions ASTM, API and ASME
Size in Inch 1/8 TO 30
Specialized in Large Diameter Size Supplier
Type Fabricated, Seamless, ERW, Welded, LSAW Supplier and Manufacturer
Length Single Random/ Double Random/ Cut Length
Form Square/ Rectangular/ Round/ Hydraulic
Schedule Schedule 30, Schedule 160, Schedule 120, Schedule 80, Schedule 20, XXS, XS, Schedule 40, Schedule 140, Schedule 80, Schedule 60, STD Supplier and Manufacture
End Plain/ Treaded/ Beveled
Pipe Marking All Pipes are marked as follows: Supplier or Manufacturer’s Name, Grade, OD, Standard, Thickness, Length, Heat No.





ASME SA 312 Tp316Ti Welded Pipe Tolerance

Outer Diameter in MM Tolerance in MM
35 to 38 +/- 0.15
4 to 35 +/- 0.08
60 and above +/- 0.25
38 to 60 +/- 0.20



ASTM A312 TP 316TI pipe Chemical Formula

Grade Carbon Manganese Silicon Phosphorous Sulfur Chromium Molybdenum Nickel Nitrogen
316Ti Stainless Steel Minimum – – – – – 16.0 2.00 10.0 –
Maximum 0.08 2.0 0.75 0.045 0.030 18.0 3.00 14.0 –





SS UNS S31703 Welded Pipe Mechanical Characteristics

Grade Tensile Strength Minimum Yield Strength Minimum Elongation Minimum Hardness
Rockwell B Maximum Brinell Maximum
316Ti Stainless Steel 515 205 35 75 205





316ti Stainless Steel Efw Tubing Physical Properties

Grade Density Elastic Modulus Mean Coeff. of Thermal Expansion Thermal Conductivity Specific Heat 0 To 1000C Electrical Resistivity
0 To 1000 C 0 To 3150 C 0 To 5380 C at 1000 C at 5000 C
316L 8000 193 15.9 16.2 17.5 16.3 21.5 500 740







ASTM TP 304 Inox Stainless Steel Pipe Tube 309S 310S 316ti 321 347H 2507



ASTM TP 304 Inox Stainless Steel Pipe Tube 309S 310S 316ti 321 347H 2507





Factory

ASTM TP 304 Inox Stainless Steel Pipe Tube 309S 310S 316ti 321 347H 2507



Why Choose Us?

1. who are we?
We are based in Wuxi, China, start from 2019,sell to Domestic Market and Abroad Market. There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production; Always final Inspection before shipment;

3.what can you buy from us?
stainless steel plate,stainless steel coil,stainless steel sheet,stainless steel pipe and tube,sainless steel bar

4. why should you buy from us not from other suppliers?
Runs perennial exports of quality assured steel mills ,including Shanxi TISCO, Baosteel, Shanghai Krupp, Ningbo Baoxin, Guangzhou Lianzhong, Zhangjiagang Pohang, Qingdao Pohang, Sweden AvestaPolarit, Finland OUTKUMPU, Spain Acerinox, South Africa Columbus
