ASTM A106 Seamless Carbon Steel Pipe 100mm Cold Rolled

Wuxi Laiyuan Special Steel Co., Ltd.
Contact Now

ASTM A106 Seamless Carbon Steel Pipe 100mm Cold Rolled

Brand Name : TISCO BAOSTEEL

Model Number : Carbon Steel Sheet

Certification : SGS BV

Place of Origin : China

MOQ : 1 ton

Price : To be negotiated

Payment Terms : L/C, T/T

Supply Ability : 8,000 ton per month

Delivery Time : 10-15 days after advance payment

Packaging Details : Kraft paper, wooden case, packaging according to customer requirements

Name : ASTM A106 Gr.B Seamless Carbon Steel pipe/ A106 GR.B seamless carbon steel tube

Length : 1000-12000mm,As Customers' Requirement

Surface : Galvanized Coated,Black Painted,PE coated,Black Painting or Galvanized,etc.

Thickness : 0.5-100mm,6-400mm,1mm-120mm,0.15mm-300mm

Width : 600-2500mm,600mm-1250mm,1.8m,305mm/355mm/455mm/510mm

Material : a36 A283 A387 1008 4320 SS400 S235jr

Contact Now

ASTM A106 Gr.B Seamless Carbon Steel pipe/ A106 GR.B seamless carbon steel tube











Specifications





Product Name
Carbon steel pipe
Material

Q195 = S195 / A53 Grade A
Q235 = S235 / A53 Grade B / A500 Grade A / STK400 / SS400 / ST42.2
Q345 = S355JR / A500 Grade B Grade C



10#,20#,45#,Q235,Q345,Q195,Q215,Q345C,Q345A

16Mn,Q345B,T1,T2,T5,T9,T11,T12,T22,T91,T92,P1,P2,P5,P9,P11,P12,P22,P91,P92,

15CrMO,Cr5Mo,10CrMo910,12CrMo,13CrMo44,30CrMo,A333 GR.1,GR.3,GR.6,GR.7,etc

SAE 1050-1065
Color
Clean, blasting and painting or as required
Technique
Hot rolled/Cold rolled
Used
Shock absorber,Motorcycle accessories,drill pipe,Excavator accessories,Auto part,hight pressure boiler tube, honed tube,Transmission shaftetc
MOQ
5tons.We also can accept sample order
Capacity
200,000 tons/year
Shipment time
Within 15-20 days after receiving advance payment







Chemical Requirements


  Grade A Grade B Grade C
Carbon max. % 0.25 0.30* 0.35*
*Manganese % 0.27 to 0.93 *0.29 to 1.06 *0.29 to 1.06
Phosphorous, max. % 0.035 0.035 0.035
Sulfur, max. % 0.035 0.035 0.035
Silicon, min.% 0.10 0.10 0.10
Chrome, max. % 0.40 0.40 0.40
Copper, max. % 0.40 0.40 0.40
Molybdenum, max. % 0.15 0.15 0.15
Nickel, max. % 0.40 0.40 0.40
Vanadium, max.% 0.08 0.08 0.08





Tensile Requirements

  Seamless
  Grade A Grade B Grade C
Tensile Strength, min., psi 48,000 60,000 70,000
Yield Strength, min., psi 30,000 35,000 40,000





Mechanical Tests Specified

Tensile Test — NPS 8 and larger — either transverse or longitudinal acceptable Smaller than NPS 8 — weighed in lots. Larger sizes — by length. Flattening Test — NPS 2-1/2 and larger. Bending Test (Cold) — NPS 2 and under.



  Degree of Bend   Diameter of Mandrel
For Normal A106 Uses 90   12 x nom dia. of pipe
For Close Coiling 180   8 x nom dia. of pipe







*ASTM A 106 grade B Seamless Pressure Pipe



B) Unless otherwise specified by the purchaser, for each reduction of 0.01 % below the specified carbon maximum, an increase of 0.06 % manganese above the specified maximum will be permitted up to a maximum of 1.65 %.



*ASME SA 106 grade B Seamless Pressure Pipe



B) For each reduction of 0.01 % below the specified carbon maximum, an increase of 0.06 % manganese above the specified maximum will be permitted up to a maximum of 1.35 %.





ASTM A106 Seamless Carbon Steel Pipe 100mm Cold Rolled



ASTM A106 Seamless Carbon Steel Pipe 100mm Cold Rolled







Payment Terms



1.Payment: T/T, L/C, Western Union, MoneyGram,PayPal; 30% deposits; 70% balance before delivery.



2.MOQ: 1pcs



3.Warranty : 3 years



4.Package Informations: 1) EXPORT, In 20 feet (GW 25 ton) or 40 feet Container (GW 25 ton)



2)as customer's requirement



Why choose us?

(1) The leading exporter in China special steel industry.

(2) Large stocks for various sizes, fast delivery date.

(3) Good business relationship with China famous factories.

(4) More than 7 years steel exporting experience.

(5) Good after-sales service guarantee.
